Pompa peristaltica digitale LOCTITE EQ PU20

The LOCTITE EQ PU20 peristaltic hose pump transports low viscosity liquids by means of pressure displacement, exerted via a rotating rotor on a liquid-carrying hose. Usually, these pumps are chosen when liquids are hazardous or difficult to handle and it is advisable to minimize operator contact with them. Another reason is that peristaltic pumps operate without a compressed air supply. Dosing times can be set from 0.01 - 99.99 seconds, with flow rates of 0.01-6 ml/min when using PTFE tubing. The pump operates in two directions, allowing back suction to prevent possible dripping of the liquid. When dispensing light-curing adhesives, only black hoses may be used. This prevents the adhesive from curing in the hoses.

• No compressed air required, air pockets in the product are avoided

• Immediate reversal of pumping direction achieves back suction, interrupts liquid flow and prevents dripping

• Adjustable vacuum run-on time control

• Convenient to use, easy hose replacement

• Digital setting and display of motor speed

• Digital time display

• "Teach In" and program memory function

• Conveys forward and backward

• Power supply: 110/220 VAC; 50/60 Hz.

• Dosing time range: 0.01-99.99 seconds

• Direction of rotation: clockwise or counterclockwise

• Reverse suction: Programmable by reversing the direction of rotor rotation.

• Scope of delivery:

  • 1 PU20 Digital peristaltic pump

  • 1 manual dosing valve

  • 1 instruction manual

  • 1 Adaper 1,6mm

  • 1 Adaper 2,0mm

  • 1 Adaper 2,5mm

  • 1 Adaper 3,2mm

  • Tube, Black, 1.4mmx0.3mm wall thickness x length

  • Tubing, Black, 1.0mmx0.3mm wall thickness x 1.0 length

  • Tubing, White, 1.4mmx0.3mm wall thickness x 1.0 length

  • Tubing, White, 1.0mmx0.3mm wall thickness x 1.0 length
